SuperPro Differential Drop Kit Toyota Hi-Lux 2005-on TRCHILUXDD

SuperPro Differential Drop Kit Toyota Hi-Lux 2005-on TRCHILUXDD

When lifting the 2005 to current model Hilux 4WD, the Constant Velocity (CV) joints are put on an increased angle, helping to accelerate the wear on the joint and putting additional stress on the CV boots that will lead to splitting and premature failure of the CV.
The SuperPro bolt on kit corrects the geometry of the front axles and CV's by lowering the front diff approximately 25mm.
Reducing the angles the CV joints are operating at will help avoid the expensive replacement costs of CV's and boots.
This wear is accelerated further if larger & wider wheels and tyres are fitted.Suspension Kit

Kit includes:

• 6 x Spacers
• 6 x Bolts
• 8 x Washer(s) - used for Steel
• 2 x Nuts

Suitable for:

• Toyota Hilux KZN25R, KUN26R, GGN25 All-wheel Drive (2005 to 2015)
• Toyota Hilux GGN125 All-wheel Drive (2015 and later)
• Toyota Hilux GUN125 All-wheel Drive (2015 and later)
• Toyota Hilux GUN126 All-wheel Drive (2015 and later)
• Toyota Land Cruiser KZJ120 Series All-wheel Drive (2003 to 2010)
• Toyota Land Cruiser 150 Series All-wheel Drive (2010 and later)
